Add the following code in the page load function to allow the devexpress dashboard connect to database and to create custome queries
protected void Page_Load(object sender, EventArgs e) {
DashboardFileStorage
dashboardFileStorage = new DashboardFileStorage("~/App_Data/Dashboards");
ASPxDashboard1.SetDashboardStorage(dashboardFileStorage);
// Uncomment this string to allow end users to create new data sources
based on predefined connection strings.
ASPxDashboard1.SetConnectionStringsProvider(new DevExpress.DataAccess.Web.ConfigFileConnectionStringsProvider());
DataSourceInMemoryStorage
dataSourceStorage = new DataSourceInMemoryStorage();
// Registers an SQL data source.
//DashboardSqlDataSource sqlDataSource = new
DashboardSqlDataSource("SQL Data Source",
"NWindConnectionString");
//SelectQuery query = SelectQueryFluentBuilder
// .AddTable("SalesPerson")
// .SelectAllColumnsFromTable()
// .Build("Sales
Person");
//sqlDataSource.Queries.Add(query);
//dataSourceStorage.RegisterDataSource("sqlDataSource",
sqlDataSource.SaveToXml());
// Registers an Object data source.
DashboardObjectDataSource
objDataSource = new DashboardObjectDataSource("Object Data Source");
objDataSource.DataId = "Object Data Source Data Id";
dataSourceStorage.RegisterDataSource("objDataSource", objDataSource.SaveToXml());
// Registers an Excel data source.
DashboardExcelDataSource
excelDataSource = new DashboardExcelDataSource("Excel Data Source");
excelDataSource.ConnectionName = "Excel Data Source Connection
Name";
excelDataSource.SourceOptions = new ExcelSourceOptions(new ExcelWorksheetSettings("Sheet1"));
dataSourceStorage.RegisterDataSource("excelDataSource",
excelDataSource.SaveToXml());
ASPxDashboard1.SetDataSourceStorage(dataSourceStorage);
ASPxDashboard1.EnableCustomSql = true;
ASPxDashboard1.EnableJsonDataSource
= true;
ASPxDashboard1.EnableTextBoxItemEditor = true;
ASPxDashboard1.AllowExecutingCustomSql=
true;
ASPxDashboard1.AllowCreateNewDashboard = true;
ASPxDashboard1.AllowCreateNewDashboard = true;
ASPxDashboard1.AllowCreateNewJsonConnection = true;
ASPxDashboard1.AllowExportDashboard
= true;
ASPxDashboard1.AllowExportDashboardItems = true;
ASPxDashboard1.AllowInspectAggregatedData = true;
ASPxDashboard1.AllowInspectRawData
= true;
ASPxDashboard1.AllowMaximizeItems =
true;
ASPxDashboard1.AllowOpenDashboard =
true;
ASPxDashboard1.AllowReadUnlistedColumnsFromClientApi = true;
}
protected void DataLoading(object sender, DataLoadingWebEventArgs e) {
if(e.DataId == "Object Data Source Data Id") {
e.Data = Invoices.CreateData();
}
}
protected void ConfigureDataConnection(object sender, ConfigureDataConnectionWebEventArgs
e) {
if(e.ConnectionName == "Excel Data Source Connection
Name") {
ExcelDataSourceConnectionParameters
excelParameters = (ExcelDataSourceConnectionParameters)e.ConnectionParameters;
excelParameters.FileName =
HostingEnvironment.MapPath(@"~/App_Data/Sales.xlsx");
}
}
